Miniature circuit breaker C101L 10A 1P 10kA Curve C
In stock
(see where)
SKU: 41103C
Available in stock: 394 - the delivery time is 1 to 2 days.
For orders over stock - the delivery time is from 30 to 40 days.
BGN 5.86 /3,00 €
BGN 5.86 /3,00 €
-
+
Characteristics
Tripping curve
C
Rated current(A)
10 A
Rated voltage
230V 50/60Hz
Electrical wear resistance (number of cycles):
≥4000
Mechanical wear resistance (number of cycles)
≥20000
IP code
IP>20
Rated breaking capacity Ics
75% Icu
Isolating voltage
≥2000V, 1 min at impulse wave 1.2/50μs
Class of current limiting
3
Recommended conductor (mm²)
1.5
Breaking capacity (kA)
10
Number of poles
1P
Mounting
on DIN rail
Product category
A
Brand
ELMARK
