Digital monitoring voltage relay MN4 63A 4P 400V
In stock
(see where)
SKU: 41907
Available in stock: 21
For orders over stock - the delivery time is from to days.
BGN 160.82
-
+
Characteristics
Rated current(A)
63 A
Rated voltage
400VAC
Pollution degree
2
Mechanical life
100 000
Operating voltage
140-500V AC; 50/60Hz (Three-phase)
Voltage power off time
0-400s
Current power off time
0-30s
Time range setting step
1s
Relative humidity
45-90% Rh
Voltage range setting step
1V
Power consumption
≤ 1.5W
Altitude
up to 2000m
Number of poles
4P
Dimensions
72x80x66mm
Mounting
on DIN rail
Over-voltage protection range
390-500V AC
Under-voltage protection range
140-370VAC
Over-current protection range
1-63A
Brand
ELMARK
Description
FUNCTIONS
• Under-voltage protection
• Over-voltage protection
• Over-current protection
FACTORY SETTING
• Over-voltage trip value: 420V
• Under-voltage trip value: 210V
• Over-current trip value: 63A
• Voltage power off time: 2s
• Starting delay time: 2s
• Current power off time: 2s
