Crimping pliers YQK- 300
Out of stock
SKU: 59301
Characteristics
Characteristics
Length of the instrument (mm)
500
Insulation
No
Max. section of the conductor
Cu:240mm/Al:300mm²
Size of the crimping element
10-300 mm²
Dimensions (L × W × H)
-
Warranty
2 years
Product category
C
Brand
ELMARK
Description
Technical characteristics:
- Widht of the element: 22mm
- Shape of the crimping element: hexahedral
- Size of the crimping element: 10, 16, 25, 35, 50, 70, 95, 120, 150, 185, 240, 300mm2
- Section of the crimped conductors:
= Al conductors: from 10 to 300mm2
= Cu conductors: from 10 to 240mm2
- Pressing strength: 100kN
- Lenght: 500mm
Functions:
- Crimping of aluminum or copper conductors with cable terminals or bush in the corresponding size
Advantages:
- Metal box for the instrument
- A set of congestion hoops for the hydraulic cylinder
