ABB Molded case circuit breaker XT5N 630 Ekip Dip LS/I In=630 3p F F 630 A
In stock
(see where)
SKU: M518408
Available in stock: 2 - the delivery time is 1 to 2 days.
For orders over stock - the delivery time is from 10 to 20 days.
€754.55
-
+
Characteristics
Type Product
Molded case circuit breaker
Series
Tmax XT
Kind
Breakers
Type
Electronic
Number of poles
3P
Rated current(A)
630A
Electrical Durability
120 cycles per hour 5000 cycle
Mechanical Durability
240 cycles per hour 20000 cycle
Rated Impulse Voltage
8 kV
Rated Operational Voltage
690 V AC
Rated Insulation Voltage
1000 V
Rated Service S/C Capacity
(220 V AC) 70 kA (230 V AC) 70 kA (240 V AC) 70 kA (380 V AC) 36 kA (415 V AC) 36 kA (440 V AC) 36 kA (500 V AC) 25 kA (525 V AC) 25 kA (690 V AC) 20 kA
Rated Uninterrupted Curr.
630 A
Release
Ekip Dip LS/I
Rated Ult. S/C Capacity
(220 V AC) 70 kA (230 V AC) 70 kA (240 V AC) 70 kA (380 V AC) 36 kA (415 V AC) 36 kA (440 V AC) 36 kA (500 V AC) 25 kA (525 V AC) 25 kA (690 V AC) 20 kA
S/C Performance Level
N
Dimensions (L × W × H)
205 x 103.5 x 140
Warranty
2 years
Product category
B
Brand
ABB
